Football pitch/Stadium lighting solutions

designs to meet recommended lux levels for training pitches and main pitches in all divisions

OutdoorindoOR

Football Icon

FOOTBALL LIGHTING

In Football, the striker is not the only thing that must hit the target. Regardless of the division or the stadium - lighting must provide sufficient coverage so that players can use their full skill set.

Whether natural or artificial, Kellwood Lighting can provide solutions for indoor and outdoor pitches of all sizes and competition levels. Please see the tables below for technical information relating to lux levels, and uniformity.

Proven Benefits

Kellwood's football pitch lighting design consultants always aim to represent the most competitive high-end option and will endeavour to find the best possible product for your requirements.

Discuss your football pitch

  • Lighting Design of Annan Football Club
  • Outdoor 8 Column Football Pitch Lighting Design
  • Indoor football pitch lighting project

LUX levels for Outdoor Football Pitches

ApplicationTypical UseHorizontal
Illuminance		RaGlareNotes
Eave (LUX)Emin/Eave
Class 1International500>0.7>60<50Non-Televised
Class 2Regional200>0.6>60<50-
Class 3Local75>0.5>20<50Higher Ra Recommended

IMPORTANT NOTE: data is compiled from outdoor-football-specific lighting publications. However, these are recommendations only; careful consideration must go into every unique environment.

The Football Association, Football League and Premier League will require particular lighting specifications in accordance with UEFA and FIFA criteria for competition and stadia provision. Consult club licensing manuals for lighting levels.

Popular Features and Accessories

Backspill Guard

Backspill Guard

Forward Throw Option

Forward Throw Optics

Marine Grade Finish

Marine Grade

Wireless Controls

Smart Controls

Mounting Options

Mounting Types

CONTACT KELLWOOD TO DISCUSS YOUR Football Pitch LIGHTING PROJECT

Class 1 (National) - 8 Pole Solution

  • 15m poles
  • 8No. Lights per Pole
  • 920W Ayrton 3 Series
  • IESNA Type IV Optic with Backspill Guard
  • Tilt = 10°
  • Eav = 500 Lux
  • Uo = 0.7
Class 1 Outdoor Football Layout

Class 2 (Regional) - 8 Pole Solution

  • 15m poles
  • 3No./4No. Lights per Pole
  • 610W Ayrton 3 Series
  • IESNA Type IV Optic with Backspill Guard
  • Tilt = 10°
  • Eav = 200 Lux
  • Uo = 0.78
Class 2 Outdoor Football Layout

Class 3 (Local) - 8 Pole Solution

  • 15m poles
  • 2No./3No. Lights per Pole
  • 460W Ayrton 3 Series
  • IESNA Type IV Optic with Backspill Guard
  • Tilt = 10°
  • Eav = 75 Lux
  • Uo = 0.78
Class 3 Outdoor Football Layout

LUX levels for Indoor Football Pitches

ApplicationTypical UseHorizontal
Illuminance		Vertical
Illuminance
Eave (LUX)Emin/EaveEave (LUX)Emin/Eave
Class 1International7500.760<30
Class 2Regional5000.660<30
Class 3Local2000.520<30

IMPORTANT NOTE: data is compiled from indoor-football-specific lighting publications. However, these are recommendations only; careful consideration must go into every unique environment.

Popular Features and Accessories

Wireless Controls

Smart Controls

Wire Guard

Wire Guard

Mounting Types

Mounting Types

Emergency Options

Emergency

Wattage

Power

IMPORTANT NOTE: data is compiled from indoor-football-specific lighting publications. However, these are recommendations only; careful consideration must go into every unique environment.

CONTACT KELLWOOD TO DISCUSS YOUR five-aside Football LIGHTING PROJECT

Class 1 (National) - 8 Row Surface Mounted Solution

  • Mount height 10.5m
  • 56No. Lights
  • 920W Aytron 3 Series
  • 90° Optic
  • Eav = 750
  • Uo = 0.7
Class 1 Indoor Football Layout

Class 2 (National) - 8 Row Surface Mounted Solution

  • Mount height 10.5m
  • 56No. Lights
  • 610W Aytron 3 Series
  • 90° Optics
  • Eav = 500
  • Uo = 0.7
Class 2 Indoor Football Layout

Class 3 (National) - 8 Row Surface Mounted Solution

  • Mount height 10.5m
  • 56No. Lights
  • 460W Aytron 3 Series
  • 90° Optic
  • Eav = 300
  • Uo = 0.7
Class 3 Indoor Football Layout
Football Wireless Lighting Controls

Wireless Lighting Controls suitable for Football

Kellwood's wireless lighting controls for football can offer numerous benefits, such as energy efficiency, cost savings, operational efficiency, improved maintenance, and scalability.
